TOP DRIVES

Electric Top Drives

Hydraulic Top Drives

Features

Drillmec designs are matched to provide top performance combined with reliability and optimized operational costs

Titolo

ELECTRIC TOP DRIVES

In the oil & gas industry top drive technology is used to increase performance and safety; from Drillmec solid experience in manufacturing hydraulic pipe handling and top drives, we introduce the ETD Series. The Drillmec Electric Top Drive is designed as transportable as well as permanent installed unit for deep drilling rigs with different mast types. The System is powered by an AC motor. The ETD Series is controlled by a separate control panel.



HYDRAULIC TOP DRIVES

Drillmec manufactures a full range of hydraulic top drives. Drillmec HTD series top drives can be fitted to almost any rig in order to increase the performance and help in operations such as directional or horizontal drilling. Drillmec designs top drive rails and torque tube starting from drawings of the customer rig or from data collected by our technicians directly on the rig field.

The torque tube provide the connection between the new HTD top drive and the existing rig. The HTD top drive is supplied with an independent hydraulic power pack and controls and with a transportation cradle designed to hold it and help in moving.

Main features:

• Hanger assembly with integrated Counterbalance cylinders

• Standard washpipe

• Link-tilt-system with position monitoring designed for high impacts

• Remote-controlled and manual IBOP

• Backup Clamp to make up and break the Top Drive drill pipe connection

• Guide rail system inducing the torque within the mast

• Electrical service loop

• Suitable for installation on any kind of mast and derrick

Specs

ELECTRIC TOP DRIVES Max Pull Up Static Max Drilling Torque Max Make Up Torque Max Break Out Torque Power Rating Max Speed

mt

lbs

Nm

lbs*ft

Nm

lbs*ft

Nm

lbs*ft

kW

hp

rpm

ETD 250

245

550,000

43,200

31,662

48,000

35,400

60,000

44,250

450

600

200

ETD 375

340

750,000

72,000

53,100

85,000

62,692

108,460

80,000

850

1150

184

ETD 500

498

1,000,000

70,000

51,600

85,000

62,692

106,630

78,646

850

1150

219

ETD 750

680

1,500,000

80,000

59,000

105,000

77,444

130,000

95,883

850

1150

219

HYDRAULIC TOP DRIVES Max Pull Up Static Max Drilling Torque Max Make Up Torque Max Break Out Torque Power Rating Max Speed

mt

lbs

Nm

lbs*ft

Nm

lbs*ft

Nm

lbs*ft

kW

hp

rpm

HTD 250C

226

500,000

36,000

26,550

39,000

28,765

43,610

32,170

403

540

180

HTD 350

317

700,000

39,240

28,941

53,000

39,090

63,000

46,466

470

630

190
